The lowest table in the line: 495 millimetres without the mattress, which is what seated surgery calls for, and 505 millimetres of lift travel. It takes 350 kilograms on a four point support structure, and three dimensional modelling software watches the angles in real time to warn before two movements collide.
| Dimensions | 2040 mm long and 520 mm wide without the rail. Height from 680 to 950 mm without the mattress, and from 495 mm in the ultra low position |
|---|---|
| Safe working load | 350 kg |
| Trendelenburg and reverse | 30 and 30 degrees |
| Lateral tilt | 25 degrees to each side |
| Back plate | 85 degrees up and 45 down |
| Head plate | 60 degrees up and 90 down, detachable |
| Leg plates | 20 degrees up and 90 down, splitting to 180 degrees |
| Flex and reflex | 225 and 95 degrees |
| Kidney bridge and shift | 130 mm lift and 355 mm longitudinal shift |
| Drive | Four electro-hydraulic systems |
| Power | 100 to 240 V AC and a rechargeable 24 V 13 Ah battery, with 8 hours of charging |
| Control | 17 button hand control and a 14 button column panel |
Technical information published by the manufacturer.
